Fluoroseal brand PFA-lined plug valves (origin Canada) are indicated for corrosive fluids, such as different types of acids.

Main features:

• Robust internal and external seal totally adjustable, bidirectional
• Body and cap coatings, set by a series of milano grooves and anchoring holes
• Epoxy's external coating resists atmospheric corrosion
• Internal lining of virgin pfa, without pigmentation
• Without cavities
• Without lubrication; It does not require maintenance
• Operation a quarter back
• Steel label for low emissions

Materials:

Body shell and center cap conform to ASTM A216 WCB, both coated with virgin PFA, unpigmented.

Available sizes:

½» – 12″ / DN 15 – DN 300

Pressure classes:

Asme Class 150/300 - Nominal Configuration
From PN 16

Since 2025, Drotec has been 𝗲𝘅𝗰𝗹𝘂𝘀𝗶𝘃𝗼 𝘆 𝗼𝗳𝗶𝗰𝗶𝗮𝗹 from Fluoroseal for Argentina, complementing its lines of coated pumps, hoses and accessories for fluid distribution.

Applications: Refineries – Chemical and petrochemical – Liquid gas plant

Horizontal pump for severe service with loss-free magnetic coupling, without mechanical seal. For bombing aggressive, explosive and toxic liquids, acids and hydrocarbons.

• Flow rate: up to 4000 m3/h
• Height: up to 350 m
• Minimum Temperature: -120°C – Maximum Temperature: 350°C
• Materials in contact with the liquid: AISI 316, steels, bushings and sleeves of Silicon Carbide, Hastelloy. On request executions in superalloys and special materials.

Separating the wet part of the pump from the atmosphere using an insulating shell is the best solution for pumping aggressive, explosive and toxic liquids, hydrocarbons, heat transfer fluids and difficult-to-seal liquids.
The hermetic sealless system is the best solution for the chemical, pharmaceutical and petrochemical industries.
A wide range of pumps covers different performances.

Drotec is the official and exclusive distributor of M Pumps in Argentina.

Magnetically coupled pumps are designed so that part of the main flow flows out the front of the impeller through the shaft support and thrust ring, lubricating the assembly that is responsible for axial thrust.

If the pump works without fluid, the consequences are fatal for the equipment.

That is why at DROTEC we say: DO NOT OPERATE MAGNETIC COUPLED PUMPS DRY.

However, we know that each plant and process has particularities and different demands that make it sometimes difficult to guarantee the above.

? 🤔

To protect the equipment from dry work, Drotec offers a power monitor that instantly measures the power consumed by the equipment and compares it with predetermined and fixed values ​​of high power cut-off and low power cut-off.

?????????????????? 𝗽𝗼𝘁𝗲𝗻𝗰𝗶𝗮? 🤓

If the high cut-off value is exceeded or is lower than the low cut-off value, the protector disables the equipment.

🔖We invite you to contact our team of technical advisors for more information and request for quotes:

✉ ventas@drotec.com.ar
📱02229-492344 / 02229-492293 / 02229-492388 / 02229-492570
💻 Webcotization: https://lnkd.in/d6H2KgkU

Manufactured 100% in our plant in Argentina, the main applications of these centrifugal pumps are liquids with solids in suspension, sludge and slurries. They are suitable for continuous service and industrial processes. Recommended for corrosive liquids with the use of appropriate materials. Suitable for specific weights greater and less than 1.00 and viscosities greater than that of water.

The cantilever impeller allows passage of large suspended solids. The impeller of these centrifugal pumps can be of the closed type or open type of swirl or vortex type.

DISEÑO BACK PULL OUT

Its design allows the rotating parts of the pump to be disassembled without removing suction or discharge pipes using a coupling with spacer.

For more information you can visit our website:

FluoroSeal®️ coated ball valves offer direct flow, providing positive shutoff with minimal pressure drops and flow turbulence.

Since the ball is independent of the stem, it has a certain freedom of movement along the axis of the valve in the closed position, without rotating against the stem. When line pressure is applied to the closed ball, it moves slightly downstream to maintain contact with the downstream seat, where the primary seal occurs.

Lined ball valves can generally be installed regardless of flow direction and are ideal for automation and flow control as they feature an ISO mounting plate.

FluoroSeal's fully PFA lined standard ball valve uses a ductile iron housing with stainless steel ball cores and stem. being ideal for corrosive liquid applications.

Available sizes
½» – 6″ / DN 15 – DN 150
Pressure classes

ASME Clase 150 / PN10-16

The main features are:

▪️LOW EMISSIONS STEM SEAL

FluoroSeal lined ball valves feature very low fugitive emissions due to the use of fully adjustable, pre-compressed PTFE packing rings.
-Independent test data according to ISO 15848-1 shows an average fugitive emissions rate of less than 10 ppm

▪️FULL PASS DESIGN

▪️UPPER SEAT DESIGN

All FluoroSeal coated ball valves come standard with the high-performance self-compensating GF2P (second generation PTFE) seat.

▪️COATING

The coating is virgin PFA without pigmentation, which allows the valves to be used in food services and other applications that require high purity.

▪️ANTI EXPLOSION STEM

The fully FluoroSeal coated ball valve stem design prevents stem bursting even if the gland assembly is removed.

▪️STANDARDIZED ACTUATOR ASSEMBLY ACCORDING TO 𝗜𝗦𝗢 𝟱𝟮𝟭𝟭

▪️ANTISTATIC DESIGN

The year is not over yet, we have time for more! 🏭✨

Office 𝗱𝗲 𝘁𝗲𝗳𝗹𝗼𝗻 𝗮𝘂𝘁𝗼𝗹𝘂𝗯𝗿𝗶𝗰𝗮𝗱𝗮𝘀 for an important company dedicated to the transportation of LNG:

1) 2″ valves with specific paint scheme for GAS compressor plants, 𝗮𝘂𝘁𝗼𝗺𝗮𝘁𝗶𝘇𝗮𝗱𝗮𝘀 with FluoroSeal Group actuator and limit box.

2) 1″ and 2″ manually operated valves brand 𝗙𝗹𝘂𝗼𝗿𝗼𝘀𝗲𝗮𝗹.

The Oil and Gas industry is developing and projected with a very good perspective. At 𝗗𝗿𝗼𝘁𝗲𝗰, we seek to supply our clients with high quality products and offer after-sales service according to each client and market.
