Coating ball valve
Coating ball valve
- With living load, stem seal for low emissions
- Total step design
- Body, ball and stem covered with virgin pfa, without pigmentation
- Central Slaughter and Stainless Steel Ball
- Hermetic and robust seats
- Metal-metal body joint
- Expulsion -proof stem
- SOport according to ISO 5211
- Available sizes
- ½” – 6″ / DN 15 – DN 150
Pressure classes
- ASME Clase 150 / PN10-16
- Ductile iron body housing according to ASTM A395, ball and central stem according to ASTM A351 CF8, covered with virgin PFA, without pigmentation
- GF2P seats
- API 598
Inspection and valve testASME B16.42
Flanges with flanges for ductile iron tubesANSI B16.10, ANSI B16.5, DIN EN 558-1
Face to face and end dimensions of the valvesASME B16.34
Valves, flanges and end welded endsYour EN 1092-1
Flanges and jointsISO 15848-1 CO3
Fugitive emissionsYour EN 12266
Metal valve testsISO 5211
Flanges dimensions for the assembly of fraction actuators back
Al2O3 ceramic ball (optional)
Bola with V step for control applications (optional)
