Dragable manual cancer gear operator
Dragable manual cancer gear operator
- Simple, compact and light design
- Manufactured with cast iron housing
- Direct assembly ISO 5211
- Use in manual or pneumatic disorder
- Rapid release mechanism of pneumatic to manual and vice versa
- Special lubricant
- Outlook -proof: IP65
Disadvantible gearbox
- Smaller torque output 2,655 pg lbs (300 nm)
- Maximum torque output 195,601 PG LBS. (22,100 Nm)
Cast iron - to 80: 1, 78: 1, 98: 1, 100: 1, 118: 1
HT200 cast iron body, AISI 1045 endless axis, eccentric bushing subset and carbon steel butt screw, Aisi 1045 endless screw, sin-end screw gears
Fully molten aluminum - to 26: 1, 38: 1, 54: 1
Pressure cast aluminum body, AISI 1045 endless axis, subset eccentric bushing and carbon steel butt screw, Aisi 1045 endless screw, QT500-7 gear of ductile iron, ht200 cast iron support cover, carbon steel handle and cast iron steel
ISO 5211
Specifications for Back fraction actuators
IP65
Water resistance
